Fruit Pulping and Refining Machine

Detailed Equipment Introduction

Gain in-depth insights into Fruit Pulping and Refining Machine equipment’s working principles, application scenarios, and technical highlights.

Fruit Pulping and Refining Machine

This pulping and refining machine separates skins and residue from materials such as tomatoes, strawberries, hawthorn, red dates, goji berries and sea buckthorn. A conical screen performs the separation, with internal spray nozzles for rinsing. Single-unit and twin-unit arrangements are available.

Key Features

Combines pulping and refining to separate skins and residue from the processed material.
Conical screen structure for pulp separation.
Stainless steel frame and product-contact parts.
Automatic rinsing outlet with internal spray nozzles arranged at multiple angles.
Dynamic balancing of the rotating assembly supports steady operation.
Single-unit or twin-unit configurations can be selected to suit the processing arrangement.

Applications

Tomatoes
Strawberries
Hawthorn
Red dates
Goji berries
Sea buckthorn

Technical Specifications

Product Specifications
Model	Capacity (t/h)	Power (kW)	Blade speed (r/min)	Screen aperture options (mm)	Dimensions (mm)
HSYL-DJ-2	1–2	6	1440	0.6 / 0.8 / 1.1	1650×1100×1680
HSYL-DJ-5	3–7	15	1440	0.6 / 0.8 / 1.1	1850×1300×1680
HSYL-DJ-10	8–10	22	1440	0.6 / 0.8 / 1.1	2000×1500×1850
HSYL-DJ-15	10–15	30	1440	0.6 / 0.8 / 1.1	2200×1800×2100
HSYL-DJ-20	15–20	37	1440	0.6 / 0.8 / 1.1	2500×2000×2250

Information for Equipment Selection

Identify the material, feed preparation and required skin or residue separation.
Provide the target feed rate and required pulp texture for screen selection.
Specify the processing arrangement and available space when selecting a single- or dual-station configuration.

Send your product requirements and production layout to discuss the equipment configuration.
